DIYPC ARGB-Q18-BK Black USB3.0 ATX Mid Tower Gaming Computer Case w/ Dual Tempered Glass Panel and 4 x ARGB 120mm Fans (Pre-Installed)

More Views

Details

DIYPC

ARGB Q18 BK

Super performance

DIYPC

ARGB Q18 BK

Super performance

HIGHLY EFFICIENT

EXTREME COOLING

TEMPERED GLASS

HIGH AIRFLOW

AUTOFLOW RAINBOW FAN

DUST-PROOF

CABLE MANAGEMENT

HIGHLY EFFICIENT

EXTREME COOLING

TEMPERED GLASS

HIGH AIRFLOW

AUTOFLOW RAINBOW FAN

DUST-PROOF

CABLE MANAGEMENT

TOP I/O PORTS

With USB 3.0 HD audio

Easily accessible connections

TOP I/O PORTS

With USB 3.0 HD audio

Easily accessible connections

AIR FLOW

Effective Air Flow

Speed Up The Cooling Efficiency

AIR FLOW

Effective Air Flow

Speed Up The Cooling Efficiency

BIG Space

Support Mini ITX, Micro ATX, ATX, E-ATX, E-EATX motherboards

* If you select an E-ATX or E-EATX motherboard, install the E-ATX or E-EATX motherboard after removing the 3 motherboard fans.

MB Tray: 3 x 120mm (installed)

Rear: 1 x 120mm (installed)

Top: 3 x 120mm or 2 x 140mm (optional)

Water cooling radiator

Top: 1 x 360 / 280 / 240mm

Rear: 1 x 120mm

2.5" SSD x 4 + 3.5" HDD x 2 or 2.5" SSD x 5 + 3.5" HDD x 1

BIG Space

Support Mini ITX, Micro ATX, ATX, E-ATX, E-EATX motherboards

* If you select an E-ATX or E-EATX motherboard, install the E-ATX or E-EATX motherboard after removing the 3 motherboard fans.

MB Tray: 3 x 120mm (installed)

Rear: 1 x 120mm (installed)

Top: 3 x 120mm or 2 x 140mm (optional)

Water cooling radiator

Top: 1 x 360 / 280 / 240mm

Rear: 1 x 120mm

2.5" SSD x 4 + 3.5" HDD x 2 or 2.5" SSD x 5 + 3.5" HDD x 1

SPECIFICATIONS

Model:	ARGB Q18 BK
Product Dimensions:	450 x 225 x 498mm
Case Material:	0.9mm SPCC, Tempered Glass
Motherboard support:	E-EATX / E-ATX / ATX / MICRO ATX / ITX
Max. VGA Length:	380mm
Max. CPU Height:	190mm
Max. PSU Length:	230mm
PCI Expansion Slots:	7+3
Drive Bays:	3.5" HDD x2 + 2.5" SSD x4 or 3.5" HDD x1 + 2.5" SSD x5
Fan support:	MB Tray: 3 x 120mm or 3 x 140mm (installed) Rear: 1 x 120mm or 1 x 140mm (installed) Top: 3 x 120mm or 2 x 140mm (optional)
Radiator Support:	Top: 360 / 280 / 240mm Rear: 120mm
I/O Ports:	1 x HD Audio, 1 x Mic, 2 x USB 2.0 1x USB 3.0, Power button, Reset button

SPECIFICATIONS

Model:	ARGB Q18 BK
Product Dimensions:	450 x 225 x 498mm
Case Material:	0.9mm SPCC, Tempered Glass
Motherboard support:	E-EATX / E-ATX / ATX / MICRO ATX / ITX
Max. VGA Length:	380mm
Max. CPU Height:	190mm
Max. PSU Length:	230mm
PCI Expansion Slots:	7+3
Drive Bays:	3.5" HDD x2 + 2.5" SSD x4 or 3.5" HDD x1 + 2.5" SSD x5
Fan support:	MB Tray: 3 x 120mm or 3 x 140mm (installed) Rear: 1 x 120mm or 1 x 140mm (installed) Top: 3 x 120mm or 2 x 140mm (optional)
Radiator Support:	Top: 360 / 280 / 240mm Rear: 120mm
I/O Ports:	1 x HD Audio, 1 x Mic, 2 x USB 2.0 1x USB 3.0, Power button, Reset button

Specifications

Learn more about the DIYPC ARGB-Q18-BK

Model
Brand	DIYPC
Model	ARGB-Q18-BK

Details
Type Type	ATX Mid Tower
Color	Black
Case Material	Steel / Tempered Glass
With Power Supply	No
Power Supply Mounted Power Supply Mounted	Bottom
Motherboard Compatibility Motherboard Compatibility	Micro ATX / ATX / ITX / E-ATX
Side Panel Window Side Panel Window	Yes
LED LED	ARGB

Expansion
Internal 3.5" Drive Bays	2
Internal 2.5" Drive Bays	2 + 2
Expansion Slots Expansion Slots	7 + 3

Front Panel Ports
Front Ports	2 x USB 2.0 / 1 x USB 3.0 / Audio In & Out (HD)

Cooling System
Fan Options	Side: 3 x 120mm ARGB LED fan (pre-installed) Rear: 1 x 120mm ARGB LED fan (pre-installed) Top: 3 x 120mm or 2 x 140mm fan (Optional)
Radiator Options	Top - Up to 360mm

Dimensions & Weight
Max GPU Length	380 mm
Max CPU Cooler Height	190 mm
Max PSU Length	230 mm
Dimensions (H x W x D)	18" x 9" x 19.92"
Weight	17 lbs.

Additional Info
Features	DIYPC ARGB-Q18-BK is a panoramic ATX case with a 270° full view of your masterpiece for building high-performance system. It has front and side tempered glass panel, w/top mesh design allow optimized air flow. The case’s design has bigger interior space to accommodate and improve cooling performance (can support up to 380mm x GPU and 360mm radiator x top). It supports up to 230mm long full ATX power supply to run the most power hungry system. Advanced cable management design – routing the main cable is easy and quick through a hidden channel. There is a large space behind the motherboard for all cables, making the case a clean and beautiful look. 2 ways to control RGB Fan Lighting: Either by Manual RGB LED Button on Top I/O Panel; or if your motherboard has 5v addressable connector, this case has ARGB 5V/3 pin header ready to SYNC w/your motherboard to control RGB lighting. Supports 2 +2 x 2.5” SSD behind MB tray Supports vertical and horizontal GPU Water cooling ready – top support up to 360mm radiator Advanced bottom-mounted power supply design Top mounted IO ports - USB 3.0 for up-to-date high speed data transfer 7 fans capability (3 x 120mm ARGB fan x side, 1 x 120mm ARGB fan x rear pre-installed) provide great cooling and gaming performance Magnetic dust filter at top and bottom - easy clean Support up to 190mm CPU cooler Support up to 380mm VGA card

Additional Information
Date First Available	March 26, 2024
